Wind Turbine Blade Aerodynamics STEM Challenge (ESS05) | Middle School Earth & Physical Science (Grades 6-8)

? WIND TURBINE BLADE AERODYNAMICS STEM CHALLENGE (ESS05)

3-Page STEM Activity | Print-Ready PDF Format

Harness wind power, aerodynamic lift, and clean energy engineering! The Wind Turbine Blade Aerodynamics Challenge (ESS05) challenges middle school student teams to act as aeronautical engineers, constructing an optimized rotor blade assembly to maximize kinetic energy transfer and output in front of a test fan.

Students explore renewable energy engineering, aerodynamic lift vs. drag, blade pitch angles, rotational kinetic energy, surface area trade-offs, and average output calculations!

? WHAT IS INCLUDED IN THIS 3-PAGE PACKET?

• ? Page 1: Teacher Guide & Lesson Plan: NGSS alignment (MS-ESS3-3, MS-PS3-5), target science concepts, fan station setup guide, expected student outcomes, answer keys, and voltage/rpm testing troubleshooting tips.

• ? Page 2: Student Mission Card & Blueprint: Real-world wind energy and aerodynamics scenario hook. Clear material limits box (hub, skewers, cardstock, tape, ruler, protractor). Dedicated Wind Turbine Rotor & Blade Airfoil Schematic sketching zone.

• ? Page 3: Testing Log & Scientific Reflection: Structured Data Testing Table (blade count, pitch angle in degrees, energy output, rotational stability across 3 trials). Applied Math Connection (calculate average energy output across testing trials). Physics & environmental science reflection questions.

? CORE STEM SKILLS COVERED:

• Aeronautical & Environmental Engineering, Wind Energy Conversion

• Aerodynamic Lift, Drag, Blade Pitch Angle Optimization & Torque

• Data Logging, Output Measurements (mV/RPM/s), and Average Math

• Iterative Blade Shape Testing and Structural Stability

? WHY TEACHERS LOVE THIS RESOURCE:

• 3-Page Professional Layout: Includes a complete Teacher Guide for effortless prep, keeping student lab sheets clean and ready to print!

• Low-Cost Everyday Materials: Built using index cards or cardstock, wooden skewers, foam/cork hubs, tape, and a standard classroom box fan.

• High-Impact Renewable Energy Lab: Brings wind turbine technology and aerodynamic physics to life through exciting, measurable testing!

• Format: High-resolution, print-ready PDF format (3 Pages).

Target Grades: 6th, 7th, 8th / Middle School

Subject Area: Earth Science, Environmental Science, Physical Science, Renewable Energy, Aerodynamics
